Setting up IoTs ("S" for security) at home, apparently HomeAssistant is the tooling to use. It's Python, so at least I have a chance of understanding what goes wrong. Which it will...

Jailed HomeAssistant on FreeBSD

Overview

Some caveats:

HomeAssistant provides no support for FreeBSD (we have to tell it to ignore OS)
HomeAssistant no longer provides this style of installation, only containers are supported.
There is a FreeBSD HomeAssistant port, but it is broken.

A bit of a faff to get this to work, but it does run. We're using the latest available Python package

NOTE: When you start HomeAssistant, it will start using uv to build additional things (e.g. habluetooth)

Jail setup

The minimal-jail pkgset wasn't enough to install, but it was enough to run. I use "thin" jails that share the base jail. This ties nicely in to the breakage of the port: it needs to compile things so you need clang.

I've ended up with the folloing jail.conf file `/etc/jail.conf.d/hass.conf

hass {
        host.hostname = "hass";
        path = "/jails/hass";
        ip4.addr += "lo0|127.0.0.20/24";
        allow.raw_sockets = 0;
        exec.clean;
        exec.system_user = "root";
        exec.jail_user = "root";
        exec.start += "/bin/sh /etc/rc";
        exec.stop = "";
        exec.consolelog = "/var/log/jail_hass_console.log";
        mount.fstab = "/etc/fstab.hass";
        mount.devfs;
        devfs_ruleset = "6";
        mount.fdescfs;
        allow.set_hostname = 0;
        allow.sysvipc = 0;
        enforce_statfs = "2";
}

and in /etc/fstab.hass

/jails/basefull150 /jails/hass/basejail nullfs ro 0 0

And start the jail. Verify it is running.

Create a homeassistant user

On the host system we create a homeasisstant user ("hass" for short) without login rights or homedir. This way the process shows up under user "hass" on the host.

pw useradd hass -u 8123 -d /var/empty -s /usr/bin/nologin

In the jail, we'll give it a homedir /home/hass which we'll use for npm's storage.

jexec hass pw useradd hass -u 8123 -d /home/hass -m -s /bin/sh

Config for (temporary) internet access

pkg, git and npm need access to internet resources.

# Add to /usr/local/etc/pkg.conf
PKG_ENV {
    http_proxy = "http://squid.example.org:3128";
}

git config --global http.proxy = http://squid.example.org:3128

npm config set proxy http://squid.example.org:3128

NOTE: this works once you've installed npm using pkg

To use pkg, you must allow the following in squid

pkg.freebsd.org
pkgmir.geo.freebsd.org
(pkg0.fra.freebsd.org?)
(cloudfront.aws.pkgbase.freebsd.org?)

Your squid config will have to allow the hass jail to use

pypi.org
files.pythonhosted.org

Your squid access logs will show what went wrong.

Install

Install required packages in the jail

Adapted from this blog-post.

pkg -r /jails/hass install python314 rust

We need to create the directory in /usr/local as hass has no permissions to do so.

install -d -o 8123 -g 8123 /jails/hass/usr/local/homeassistant

Now we switch to the hass user. The rest of the install is as hass.

su -l hass
mkdir $HOME/bin $HOME/lib
export PATH=$PATH:$HOME/bin

Zigbee2MQTT

Another jail named zigbee, and a user zigbee.

The cheap dongle I bought shows up in dmesg like so

uchcom0 on uhub0
uchcom0: <vendor 0x1a86 USB Serial, rev 1.10/2.64, addr 1> on usbus1
uchcom0: CH340 detected

The device nodes are named ttyU*. To allow access to the Zigbee dongle from the jail, we need a specific devfs ruleset.

$ cat /etc/devfs.rules
[devfsrules_jail_zigbee=16]
add include $devfsrules_hide_all
add include $devfsrules_unhide_basic
add include $devfsrules_unhide_login
add path 'ttyU*' unhide group 1883 mode 660

The jail configuration is internal only with the specific devfs ruleset.

zigbee {
        host.hostname = "zigbee";
        path = "/jails/zigbee";
        ip4.addr += "lo0|127.0.0.21/24";
        allow.raw_sockets = 0;
        exec.clean;
        exec.system_user = "root";
        exec.jail_user = "root";
        exec.start += "/bin/sh /etc/rc";
        exec.stop = "";
        exec.consolelog = "/var/log/jail_zigbee_console.log";
        mount.fstab = "/etc/fstab.zigbee";
        mount.devfs;
        devfs_ruleset = "16";
        mount.fdescfs;
        mount.procfs;
        allow.mount;
        allow.set_hostname = 0;
        allow.sysvipc = 0;
        enforce_statfs = "2";
}

Create a group and user (id is the same as in devfs.rules!) and the homedir

pw -R /jails/zigbee groupadd zigbee -g 1883
pw -R /jails/zigbee useradd zigbee -u 1883 -d /usr/local/z2m -g zigbee -s /usr/sbin/nologin
install -d -o zigbee -g zigbee -m 750 /jails/zigbee/usr/local/z2m

Start the zigbee jail and open a shell as user zigbee in the jail.

Get the source (check for latest tag)

cd /usr/local
git clone --depth=1 https://github.com/Koenkk/zigbee2mqtt.git z2m
cd z2m
git remote set-branches --add origin 2.8.0
git fetch origin 2.8.0:2.8.0
git checkout 2.8.0

Your zigbee2mqtt now lives in /usr/local/z2m. For upgrading to later Zigbee2mqtt versions, add and checkout the new tag. Configure npm, install pnpm, and install zigbee2mqtt:

# Configure npm
$ npm set prefix="$HOME"
$ npm config set proxy http://squid.example.org:3128
# Install pnpm
$ npm install -g pnpm@latest-9
$ which pnpm
/usr/local/z2m/bin/pnpm
$ pnpm --version
9.15.9
# Install zigbee2mqtt dependencies
$ pnpm i --frozen-lockfile
# Install zigbee2mqtt
$ pnpm run build

This should finish without errors.

Create the rc script /usr/local/etc/rc.d/z2m

#!/bin/sh

# PROVIDE: z2m
# REQUIRE: DAEMON
# KEYWORD: shutdown

# FreeBSD rc.d script for zigbee2mqtt
#

# The z2m service has the following rc.conf options:
#
# z2m_enable (bool):    Set to YES to enable z2m
#                       Default: NO
# z2m_user (str):       The user to run z2m as
#                       Default: z2m
# z2m_group (str):      The group to run z2m as
#                       Default: z2m
# z2m_chdir (str):      The directory where z2m is installed
#                       Default: /usr/local/z2m
# z2m_datadir (str):    The directory where z2m's data is stored
#                       Default: /var/db/z2m
# z2m_restart (bool):   Set to YES if z2m should be automatically
#                       restarted after it crashes.
#                       Default: NO

. /etc/rc.subr

name=z2m
desc="zigbee2mqtt service"
rcvar=z2m_enable

load_rc_config $name

: ${z2m_enable:=NO}
: ${z2m_group:=zigbee}
: ${z2m_datadir:=/var/db/z2m}
: ${z2m_pidfile=/var/run/z2m/z2m.pid}
: ${z2m_restart=NO}
: ${z2m_user:=zigbee}
: ${z2m_chdir=/usr/local/z2m}
: ${z2m_env:="ZIGBEE2MQTT_DATA=${z2m_datadir}"}

# If z2m_restart is YES, then restart z2m when it crashes, otherwise
# daemon(8) will exit.
if checkyesno z2m_restart; then
        _restartargs="-r"
else
        _restartargs=""
fi

pidfile=${z2m_pidfile}

command=/usr/sbin/daemon
command_args="-f -H \
                -P ${pidfile} -t ${name} -T ${name} \
                ${_restartargs} \
                /usr/local/bin/node index.js"
required_files="${z2m_datadir}/configuration.yaml"

start_precmd="[ -d ${pidfile%/*} ] || install -d -o ${z2m_user} -g ${z2m_group} ${pidfile%/*}"

run_rc_command "$1"

Check and run

Inside your zigbee jail, you should see the USB dongle

/dev/ttyU0
/dev/ttyU0.init
/dev/ttyU0.lock

You can now start z2m by creating an rc-script /usr/local/etc/rc.d/z2m. This comes from the comms/hass2mqtt port.

#!/bin/sh

# PROVIDE: z2m
# REQUIRE: DAEMON
# KEYWORD: shutdown

# FreeBSD rc.d script for hass2mqtt
#

# The z2m service has the following rc.conf options:
#
# z2m_enable (bool):    Set to YES to enable z2m
#           Default: NO
# z2m_user (str):   The user to run z2m as
#           Default: z2m
# z2m_group (str):  The group to run z2m as
#           Default: z2m
# z2m_chdir (str):  The directory where z2m is installed
#           Default: /usr/local/z2m
# z2m_datadir (str):    The directory where z2m's data is stored
#           Default: /var/db/z2m
# z2m_restart (bool):   Set to YES if z2m should be automatically
#           restarted after it crashes.
#           Default: NO

. /etc/rc.subr

name=z2m
desc="hass2mqtt service"
rcvar=z2m_enable

load_rc_config $name

: ${z2m_enable:=NO}
: ${z2m_group:=hass}
: ${z2m_datadir:=/var/db/z2m}
: ${z2m_pidfile=/var/run/z2m/z2m.pid}
: ${z2m_restart=NO}
: ${z2m_user:=hass}
: ${z2m_chdir=/usr/local/z2m}
: ${z2m_env:="hass2MQTT_DATA=${z2m_datadir}"}

# If z2m_restart is YES, then restart z2m when it crashes, otherwise
# daemon(8) will exit.
if checkyesno z2m_restart; then
    _restartargs="-r"
else
    _restartargs=""
fi

pidfile=${z2m_pidfile}

command=/usr/sbin/daemon
command_args="-f -H \
                -P ${pidfile} -t ${name} -T ${name} \
                ${_restartargs} \
                /usr/local/bin/node index.js"
required_files="${z2m_datadir}/configuration.yaml"

start_precmd="[ -d ${pidfile%/*} ] || install -d -o ${z2m_user} -g ${z2m_group} ${pidfile%/*}"

run_rc_command "$1"

You can now enable the service

service z2m enable

and start!

service z2m start
